Laboratory and Chemical ApplicationsOur Quartz Petri Dishes are meticulously crafted from high-purity fused silica, offering superior properties compared to standard glass. These dishes provide exceptional UV transparency, allowing for direct UV irradiation experiments, along with outstanding high-temperature resistance for sterilization and annealing. Their inherent chemical inertness ensures no contamination or reaction with sensitive samples. Ideal for demanding cell culture, microbiology, photochemistry, and high-temperature laboratory applications.
| Property Content | Property Values |
|---|---|
| SiO2 | 99.99% |
| Density | 2.2×10³ kg/cm³ |
| Hardness | 5.5 - 6.5 Mohs' Scale 570 KHN 100 |
| Tensile Strength | 4.8×10⁷ Pa (N/mm2) (7000 psi) |
| Compression Strength | >1.1×10⁹ Pa (160,000 psi) |
| Coefficient of Thermal Expansion | 5.5×10⁻⁷ cm/cm·°C (20°C-320°C) |
| Thermal Conductivity | 1.4 W/m·°C |
| Specific Heat | 670 J/kg·°C |
| Softening Point | 1730°C (3146°F) |
| Annealing Point | 1210°C (2210°F) |
| Strain Point | 1120°C (2048°F) |
| Work Temperature | 1200°C (2192°F) |
| Electrical Resistivity | 7×10⁷ ohm cm (350°C) |
| Size | Customized |
| Logo | Customized Logo Accept |
High-Temperature Resistance
Quartz petri dishes can withstand extremely high temperatures, with long-term working temperatures ranging from 1100°C to 1250°C and short-term exposure to temperatures up to 1450°C.
Corrosion Resistance
Quartz glass is inert to almost all acids (except hydrofluoric acid), offering superior acid resistance that is 30 times greater than that of ceramics and 150 times greater than that of stainless steel.
High Light Transmittance
Quartz glass exhibits excellent light transmittance across the entire spectrum from ultraviolet to infrared. Its visible light transmittance is greater than 95%, and its maximum transmittance in the ultraviolet spectral range exceeds 85%.
Chemical Stability
Quartz glass has exceptional chemical stability and does not readily react with other chemical substances. This makes it a popular choice in laboratories, especially for experiments where maintaining the purity of the vessel is critical.
Application Scenario
Cell Culture
In biomedical research, quartz petri dishes are used for cell culture and observation because they provide a sterile and chemically stable environment.
Microbiology Research
They are used for the isolation, cultivation, and identification of microorganisms such as bacteria and fungi. Quartz petri dishes are suitable for a variety of microbiological experiments due to their high-temperature and corrosion-resistant properties.
High-Temperature Experiments
In chemical experiments requiring high-temperature processing, such as ashing and melting, quartz petri dishes are widely used because of their ability to withstand high temperatures.
Optical and Ultraviolet Experiments
Because of their high light transmittance, quartz petri dishes are useful in optical and ultraviolet light experiments, particularly in ultraviolet spectroscopy analysis where high transmittance is essential.
Quartz petri dishes can withstand extremely high temperatures. Their long-term working temperatures range from 1100°C to 1250°C, and they can withstand temperatures up to 1450°C for short durations.
Quartz petri dishes are inert to almost all acids, except for hydrofluoric acid. Their acid resistance is 30 times greater than that of ceramics and 150 times greater than that of stainless steel.
Quartz petri dishes have excellent transmittance across the entire spectrum from ultraviolet to infrared. Their visible light transmittance is greater than 95%, and their maximum transmittance in the ultraviolet spectral range is over 85%, making them very suitable for experiments requiring high light transmittance.
Quartz XRD Sample Holder
Quartz flow cells
Quartz Petri Dish
Custom Quartz Petri Dish
Quartz Cylindrical Cuvette
Quartz Round Screw-Top Cuvette
