Custom Spiral Quartz Glass Tubes & Fused Silica Coils – High Purity for Industrial Heating & Cooling

Custom Spiral Quartz Glass Tubes & Fused Silica Coils – High Purity for Industrial Heating & Cooling

    分类：

    Spiral quartz tubes are high-temperature resistant and corrosion-resistant quartz glass tubes, commonly used in high-temperature experiments and chemical analysis.

    ODIDWTL(mm)
    1mm0.5mm0.25mm1~6000mm(custom)
    1.5mm0.8mm0.35mm1~6000mm(custom)
    2mm1mm0.5mm1~6000mm(custom)
    2.5mm1.5mm0.5mm1~6000mm(custom)
    3mm2mm0.5mm1~6000mm(custom)
    3mm1mm1mm1~6000mm(custom)
    4mm3mm0.5mm1~6000mm(custom)
    4mm2mm1mm1~6000mm(custom)
    4mm1mm1.5mm1~6000mm(custom)
    5mm4mm0.5mm1~6000mm(custom)
    5mm3mm1mm1~6000mm(custom)
    5mm2mm1.5mm1~6000mm(custom)
    5.5mm3.5mm1mm1~6000mm(custom)
    6mm5mm0.5mm1~6000mm(custom)
    6mm4mm1mm1~6000mm(custom)
    6mm3mm1.5mm1~6000mm(custom)
    6mm2mm2mm1~6000mm(custom)
    6.5mm4.5mm1mm1~6000mm(custom)
    7mm5mm1mm1~6000mm(custom)
    7mm4mm1.5mm1~6000mm(custom)
    7.5mm5.5mm1mm1~6000mm(custom)
    8mm6mm1mm1~6000mm(custom)
    8mm5mm1.5mm1~6000mm(custom)
    8.5mm6.5mm1mm1~6000mm(custom)
    9mm7mm1mm1~6000mm(custom)
    9mm6mm1.5mm1~6000mm(custom)
    9mm5mm2mm1~6000mm(custom)
    10mm8mm1mm1~6000mm(custom)
    10mm7mm1.5mm1~6000mm(custom)
    10mm6mm2mm1~6000mm(custom)
    10mm4mm3mm1~6000mm(custom)
    10mm2mm4mm1~6000mm(custom)
    11mm9mm1mm1~6000mm(custom)
    11mm8mm1.5mm1~6000mm(custom)
    11mm7mm2mm1~6000mm(custom)
    11mm5mm3mm1~6000mm(custom)
    12mm10mm1mm1~6000mm(custom)
    12mm8mm2mm1~6000mm(custom)
    12mm4mm4mm1~6000mm(custom)
    13mm11mm1mm1~6000mm(custom)
    13mm10mm1.5mm1~6000mm(custom)
    13mm9mm2mm1~6000mm(custom)
    14mm12mm1mm1~6000mm(custom)
    14mm10mm2mm1~6000mm(custom)
    15mm13mm1mm1~6000mm(custom)
    15mm11mm2mm1~6000mm(custom)
    15mm9mm3mm1~6000mm(custom)
    16mm14mm1mm1~6000mm(custom)
    16mm13mm1.5mm1~6000mm(custom)
    16mm12mm2mm1~6000mm(custom)
    16mm10mm3mm1~6000mm(custom)
    17mm15mm1mm1~6000mm(custom)
    17mm14mm1.5mm1~6000mm(custom)
    18mm16mm1mm1~6000mm(custom)
    18mm15mm1.5mm1~6000mm(custom)
    18mm14mm2mm1~6000mm(custom)
    18mm12mm3mm1~6000mm(custom)
    18mm11mm3.5mm1~6000mm(custom)
    19mm17mm1mm1~6000mm(custom)
    19mm16mm1.5mm1~6000mm(custom)
    19mm13mm3mm1~6000mm(custom)
    20mm18mm1mm1~6000mm(custom)
    20mm17mm1.5mm1~6000mm(custom)
    20mm16mm2mm1~6000mm(custom)
    20mm14mm3mm1~6000mm(custom)
    25mm19mm3mm1~6000mm(custom)
    25mm21mm2mm1~6000mm(custom)
    25mm21mm2mm1~6000mm(custom)
    25mm21mm2mm1~6000mm(custom)
    25mm21mm2mm1~6000mm(custom)
    25mm20mm2.5mm1~6000mm(custom)
    25mm20mm2.5mm1~6000mm(custom)
    25mm20mm2.5mm1~6000mm(custom)
    26mm21mm2.5mm1~6000mm(custom)
    28mm24mm2mm1~6000mm(custom)
    30mm26mm2mm1~6000mm(custom)
    30mm24mm3mm1~6000mm(custom)
    35mm30mm2.5mm1~6000mm(custom)
    40mm34mm3mm1~6000mm(custom)
    40mm34mm3mm1~6000mm(custom)
    40mm34mm3mm1~6000mm(custom)
    40mm34mm3mm1~6000mm(custom)
    40mm32mm4mm1~6000mm(custom)
    40mm32mm4mm1~6000mm(custom)
    40mm32mm4mm1~6000mm(custom)
    40mm32mm4mm1~6000mm(custom)
    40mm32mm4mm1~6000mm(custom)
    45mm39mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm42mm4mm1~6000mm(custom)
    50mm42mm4mm1~6000mm(custom)
    50mm42mm4mm1~6000mm(custom)
    50mm42mm4mm1~6000mm(custom)
    50mm42mm4mm1~6000mm(custom)
    50mm42mm4mm1~6000mm(custom)
    50mm40mm5mm1~6000mm(custom)
    50mm40mm5mm1~6000mm(custom)
    60mm54mm3mm1~6000mm(custom)
    60mm54mm3mm1~6000mm(custom)
    60mm54mm3mm1~6000mm(custom)
    60mm54mm3mm1~6000mm(custom)
    60mm52mm4mm1~6000mm(custom)
    60mm52mm4mm1~6000mm(custom)
    60mm50mm5mm1~6000mm(custom)
    60mm50mm5mm1~6000mm(custom)
    80mm74mm3mm1~6000mm(custom)
    80mm74mm3mm1~6000mm(custom)
    80mm74mm3mm1~6000mm(custom)
    80mm72mm4mm1~6000mm(custom)
    80mm72mm4mm1~6000mm(custom)
    80mm70mm5mm1~6000mm(custom)
    80mm70mm5mm1~6000mm(custom)
    85mm79mm3mm1~6000mm(custom)
    90mm80mm5mm1~6000mm(custom)
    100mm94mm3mm1~6000mm(custom)
    100mm94mm3mm1~6000mm(custom)
    100mm94mm3mm1~6000mm(custom)
    100mm92mm4mm1~6000mm(custom)
    100mm92mm4mm1~6000mm(custom)
    100mm90mm5mm1~6000mm(custom)
    100mm90mm5mm1~6000mm(custom)
    120mm112mm4mm1~6000mm(custom)
    120mm110mm5mm1~6000mm(custom)
    120mm112mm4mm1~6000mm(custom)
    120mm110mm5mm1~6000mm(custom)
    130mm120mm5mm1~6000mm(custom)
    130mm124mm3mm1~6000mm(custom)
    130mm124mm3mm1~6000mm(custom)
    130mm120mm5mm1~6000mm(custom)
    130mm120mm5mm1~6000mm(custom)
    140mm130mm5mm1~6000mm(custom)
    140mm130mm5mm1~6000mm(custom)
    150mm140mm5mm1~6000mm(custom)
    150mm140mm5mm1~6000mm(custom)
    150mm140mm5mm1~6000mm(custom)
    180mm170mm5mm1~6000mm(custom)
    180mm170mm5mm1~6000mm(custom)
    180mm170mm5mm1~6000mm(custom)
    200mm190mm5mm1~6000mm(custom)
    200mm190mm5mm1~6000mm(custom)
    200mm190mm5mm1~6000mm(custom)
    1 1
    • ayment method: By wire transfer or advance payment, depending on the quantity of the order.
    • Delivery time: According to the order quantity.
    • Transportation method: Sea freight or air freight, depending on the customer.

    Remarks：

    To confirm the order, the following parameters need to be provided: ① OD ② ID ③ Thickness ④ Lengt ⑤ Quantity

    Property ContentProperty Values
    SiO299.99%
    Density2.2×10³ kg/cm³
    Hardness5.5 - 6.5 Mohs' Scale 570 KHN 100
    Tensile Strength4.8×10⁷ Pa (N/mm2) (7000 psi)
    Compression Strength>1.1×10⁹ Pa (160,000 psi)
    Coefficient of Thermal Expansion5.5×10⁻⁷ cm/cm·°C (20°C-320°C)
    Thermal Conductivity1.4 W/m·°C
    Specific Heat670 J/kg·°C
    Softening Point1730°C (3146°F)
    Annealing Point1210°C (2210°F)
    Strain Point1120°C (2048°F)
    Work Temperature1200°C (2192°F)
    Electrical Resistivity7×10⁷ ohm cm (350°C)
    SizeCustomized
    LogoCustomized Logo Accept

    High-Temperature Resistance

    Quartz tubes can withstand temperatures up to 1250°C without deformation or cracking.

    Corrosion
    Resistance

    These tubes demonstrate exceptional resistance to acids, alkalis, and other corrosive substances.

    High Light
    Transmittance

    Quartz glass provides excellent light transmission across ultraviolet to infrared spectra.

    Threaded Design

    The threaded structure on the tube body provides enhanced connectivity and sealing capabilities for threaded quartz tubes, facilitating secure connection and fixation with other equipment or components.

    Application Scenario

    未标题 1 3

    Industrial Control

    Helical quartz tubes are essential for pressure measurement, liquid level detection, and flow rate monitoring in industrial processes. Their high precision and reliability are crucial for ensuring stable and safe industrial production.

    未标题 1 14

    Scientific Research

    In biological and chemical research, these tubes facilitate measurements of minute pressure changes and interactions between solutes and solvents, providing accurate data for scientific studies.

    未标题 1 16

    Medical Devices

    Helical quartz tubes play a vital role in medical devices for measuring vital signs like blood pressure, heart rate, and respiratory rate. They also monitor pressure changes in drug delivery and dialysis equipment, contributing significantly to medical diagnostics and treatment.

    未标题 1 17

    Environmental Protection

    With growing environmental awareness, helical quartz tubes are increasingly used in environmental protection equipment such as air purifiers and wastewater treatment systems, including UV sterilizers. Their efficiency and eco-friendliness are gaining widespread recognition.

    Maintain Cleanliness

    Keep helical quartz tubes clean and free from chemical corrosion and mechanical damage to ensure measurement accuracy and prolong their lifespan.

    Avoid Extreme Conditions

    Helical quartz tubes are not suitable for measuring pressure changes under extreme high-temperature or high-pressure conditions, as exceeding their operational limits can cause damage.

    Storage environmen

    When storing quartz tubes, care should be taken to avoid exposure to mechanical vibrations, shocks, and excessively high temperatures. They should be kept in a dry, cool, and well-ventilated place, avoiding direct sunlight and high-temperature environments.

    Spiral quartz tubes have a helical shape, which helps provide a longer heating or cooling area in space-limited environments, commonly used in applications requiring uniform temperature distribution.

    The spiral shape increases the surface area, which helps improve heat exchange efficiency, and also makes the tube more robust, reducing sagging due to its own weight.

    The pitch and diameter determine the heat exchange capacity and mechanical strength of spiral quartz tubes. Smaller pitches and diameters may be more suitable for precise thermal control, while larger pitches and diameters are suitable for applications requiring a larger heat exchange area.

    1.石英激光打孔

    Laser Drilling of Quartz

    Quartz Tube with External Threads

    Threaded Quartz Tube

    3.管面螺纹

    External Thread on Quartz Tube

    Quartz Tube with Internal Threads

    Internal Threaded Quartz Tube

    Slotting of Quartz Tube Walls

    Quartz Tube Slotted

    Creating Windows on Quartz Tube Surface

    Window on Quartz Tube

    Angled Cutting of Quartz Tube

    Angled Cut Quartz Tube

    Quartz Tiles/Quartz Plates

    Quartz Tile

    Cutting Windows in Quartz Tube

    Quartz Tube with Window
