Custom Curved Quartz Glass Tubes & Precision Bent Fused Silica Tubing

Custom Curved Quartz Glass Tubes & Precision Bent Fused Silica Tubing

    分类：

    Quartz glass bend, or more commonly, bent quartz glass tubing, refers to quartz glass tubing that has been formed into a curved shape using a specific process.

    ODIDWTL(mm)
    1mm0.5mm0.25mm1~6000mm(custom)
    1.5mm0.8mm0.35mm1~6000mm(custom)
    2mm1mm0.5mm1~6000mm(custom)
    2.5mm1.5mm0.5mm1~6000mm(custom)
    3mm2mm0.5mm1~6000mm(custom)
    3mm1mm1mm1~6000mm(custom)
    4mm3mm0.5mm1~6000mm(custom)
    4mm2mm1mm1~6000mm(custom)
    4mm1mm1.5mm1~6000mm(custom)
    5mm4mm0.5mm1~6000mm(custom)
    5mm3mm1mm1~6000mm(custom)
    5mm2mm1.5mm1~6000mm(custom)
    5.5mm3.5mm1mm1~6000mm(custom)
    6mm5mm0.5mm1~6000mm(custom)
    6mm4mm1mm1~6000mm(custom)
    6mm3mm1.5mm1~6000mm(custom)
    6mm2mm2mm1~6000mm(custom)
    6.5mm4.5mm1mm1~6000mm(custom)
    7mm5mm1mm1~6000mm(custom)
    7mm4mm1.5mm1~6000mm(custom)
    7.5mm5.5mm1mm1~6000mm(custom)
    8mm6mm1mm1~6000mm(custom)
    8mm5mm1.5mm1~6000mm(custom)
    8.5mm6.5mm1mm1~6000mm(custom)
    9mm7mm1mm1~6000mm(custom)
    9mm6mm1.5mm1~6000mm(custom)
    9mm5mm2mm1~6000mm(custom)
    10mm8mm1mm1~6000mm(custom)
    10mm7mm1.5mm1~6000mm(custom)
    10mm6mm2mm1~6000mm(custom)
    10mm4mm3mm1~6000mm(custom)
    10mm2mm4mm1~6000mm(custom)
    11mm9mm1mm1~6000mm(custom)
    11mm8mm1.5mm1~6000mm(custom)
    11mm7mm2mm1~6000mm(custom)
    11mm5mm3mm1~6000mm(custom)
    12mm10mm1mm1~6000mm(custom)
    12mm8mm2mm1~6000mm(custom)
    12mm4mm4mm1~6000mm(custom)
    13mm11mm1mm1~6000mm(custom)
    13mm10mm1.5mm1~6000mm(custom)
    13mm9mm2mm1~6000mm(custom)
    14mm12mm1mm1~6000mm(custom)
    14mm10mm2mm1~6000mm(custom)
    15mm13mm1mm1~6000mm(custom)
    15mm11mm2mm1~6000mm(custom)
    15mm9mm3mm1~6000mm(custom)
    16mm14mm1mm1~6000mm(custom)
    16mm13mm1.5mm1~6000mm(custom)
    16mm12mm2mm1~6000mm(custom)
    16mm10mm3mm1~6000mm(custom)
    17mm15mm1mm1~6000mm(custom)
    17mm14mm1.5mm1~6000mm(custom)
    18mm16mm1mm1~6000mm(custom)
    18mm15mm1.5mm1~6000mm(custom)
    18mm14mm2mm1~6000mm(custom)
    18mm12mm3mm1~6000mm(custom)
    18mm11mm3.5mm1~6000mm(custom)
    19mm17mm1mm1~6000mm(custom)
    19mm16mm1.5mm1~6000mm(custom)
    19mm13mm3mm1~6000mm(custom)
    20mm18mm1mm1~6000mm(custom)
    20mm17mm1.5mm1~6000mm(custom)
    20mm16mm2mm1~6000mm(custom)
    20mm14mm3mm1~6000mm(custom)
    25mm19mm3mm1~6000mm(custom)
    25mm21mm2mm1~6000mm(custom)
    25mm21mm2mm1~6000mm(custom)
    25mm21mm2mm1~6000mm(custom)
    25mm21mm2mm1~6000mm(custom)
    25mm20mm2.5mm1~6000mm(custom)
    25mm20mm2.5mm1~6000mm(custom)
    25mm20mm2.5mm1~6000mm(custom)
    26mm21mm2.5mm1~6000mm(custom)
    28mm24mm2mm1~6000mm(custom)
    30mm26mm2mm1~6000mm(custom)
    30mm24mm3mm1~6000mm(custom)
    35mm30mm2.5mm1~6000mm(custom)
    40mm34mm3mm1~6000mm(custom)
    40mm34mm3mm1~6000mm(custom)
    40mm34mm3mm1~6000mm(custom)
    40mm34mm3mm1~6000mm(custom)
    40mm32mm4mm1~6000mm(custom)
    40mm32mm4mm1~6000mm(custom)
    40mm32mm4mm1~6000mm(custom)
    40mm32mm4mm1~6000mm(custom)
    40mm32mm4mm1~6000mm(custom)
    45mm39mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm44mm3mm1~6000mm(custom)
    50mm42mm4mm1~6000mm(custom)
    50mm42mm4mm1~6000mm(custom)
    50mm42mm4mm1~6000mm(custom)
    50mm42mm4mm1~6000mm(custom)
    50mm42mm4mm1~6000mm(custom)
    50mm42mm4mm1~6000mm(custom)
    50mm40mm5mm1~6000mm(custom)
    50mm40mm5mm1~6000mm(custom)
    60mm54mm3mm1~6000mm(custom)
    60mm54mm3mm1~6000mm(custom)
    60mm54mm3mm1~6000mm(custom)
    60mm54mm3mm1~6000mm(custom)
    60mm52mm4mm1~6000mm(custom)
    60mm52mm4mm1~6000mm(custom)
    60mm50mm5mm1~6000mm(custom)
    60mm50mm5mm1~6000mm(custom)
    80mm74mm3mm1~6000mm(custom)
    80mm74mm3mm1~6000mm(custom)
    80mm74mm3mm1~6000mm(custom)
    80mm72mm4mm1~6000mm(custom)
    80mm72mm4mm1~6000mm(custom)
    80mm70mm5mm1~6000mm(custom)
    80mm70mm5mm1~6000mm(custom)
    85mm79mm3mm1~6000mm(custom)
    90mm80mm5mm1~6000mm(custom)
    100mm94mm3mm1~6000mm(custom)
    100mm94mm3mm1~6000mm(custom)
    100mm94mm3mm1~6000mm(custom)
    100mm92mm4mm1~6000mm(custom)
    100mm92mm4mm1~6000mm(custom)
    100mm90mm5mm1~6000mm(custom)
    100mm90mm5mm1~6000mm(custom)
    120mm112mm4mm1~6000mm(custom)
    120mm110mm5mm1~6000mm(custom)
    120mm112mm4mm1~6000mm(custom)
    120mm110mm5mm1~6000mm(custom)
    130mm120mm5mm1~6000mm(custom)
    130mm124mm3mm1~6000mm(custom)
    130mm124mm3mm1~6000mm(custom)
    130mm120mm5mm1~6000mm(custom)
    130mm120mm5mm1~6000mm(custom)
    140mm130mm5mm1~6000mm(custom)
    140mm130mm5mm1~6000mm(custom)
    150mm140mm5mm1~6000mm(custom)
    150mm140mm5mm1~6000mm(custom)
    150mm140mm5mm1~6000mm(custom)
    180mm170mm5mm1~6000mm(custom)
    180mm170mm5mm1~6000mm(custom)
    180mm170mm5mm1~6000mm(custom)
    200mm190mm5mm1~6000mm(custom)
    200mm190mm5mm1~6000mm(custom)
    200mm190mm5mm1~6000mm(custom)
    1 1
    • ayment method: By wire transfer or advance payment, depending on the quantity of the order.
    • Delivery time: According to the order quantity.
    • Transportation method: Sea freight or air freight, depending on the customer.

    Remarks：

    To confirm the order, the following parameters need to be provided: ① OD ② ID ③ Thickness ④ Lengt ⑤ Quantity

    Property ContentProperty Values
    SiO299.99%
    Density2.2×10³ kg/cm³
    Hardness5.5 - 6.5 Mohs' Scale 570 KHN 100
    Tensile Strength4.8×10⁷ Pa (N/mm2) (7000 psi)
    Compression Strength>1.1×10⁹ Pa (160,000 psi)
    Coefficient of Thermal Expansion5.5×10⁻⁷ cm/cm·°C (20°C-320°C)
    Thermal Conductivity1.4 W/m·°C
    Specific Heat670 J/kg·°C
    Softening Point1730°C (3146°F)
    Annealing Point1210°C (2210°F)
    Strain Point1120°C (2048°F)
    Work Temperature1200°C (2192°F)
    Electrical Resistivity7×10⁷ ohm cm (350°C)
    SizeCustomized
    LogoCustomized Logo Accept

    High-Temperature Resistance

    Quartz glass has a softening point of approximately 1730°C and can be used continuously at 1100°C. Short-term exposure to temperatures up to 1450°C is also possible. This allows bent quartz glass tubing to remain stable and resist deformation or damage in high-temperature environments.

    Excellent Corrosion Resistance

    With the exception of hydrofluoric acid, quartz glass is virtually inert to other acids. Its acid resistance is 30 times that of ceramics and 150 times that of stainless steel. Consequently, bent quartz glass tubing can withstand exposure to a wide range of corrosive media.

    High Light Transmittance

    Quartz glass exhibits excellent light transmission properties across a broad spectral range from ultraviolet to infrared, with a visible light transmittance exceeding 93%. This makes bent quartz glass tubing ideal for applications requiring optical transparency.

    Low Thermal Expansion Coefficient

    Quartz glass has an extremely low thermal expansion coefficient, enabling it to withstand drastic temperature changes. This characteristic ensures that bent quartz glass tubing maintains its shape and performance even in environments with significant temperature fluctuations.

    Application Scenario

    未标题 1 18

    High-Temperature Heating Equipment

    Used as casing or internal tubing in equipment like chemical vapor deposition (CVD) chambers and high-temperature furnaces, capable of withstanding high temperatures and corrosive environments.

    未标题 1 19

    Other Industrial Fields

    Suitable for applications requiring high-temperature and corrosion-resistant tubing in sectors such as power generation, electronics, and healthcare.

    未标题 1 20

    Semiconductor Industry

    Quartz tubes have important applications in the semiconductor industry, serving as containers during processes such as epitaxy, diffusion, and oxidation, and as components of semiconductor boat equipment.

    未标题 1 15

    Industrial Production

    Quartz tubes can also be used in industrial production for ovens, drying equipment, and in situations that require corrosion resistance and high-temperature durability.

    Avoid Impacts and Vibrations

    While bent quartz glass tubing possesses high hardness and strength, it’s essential to avoid impacts and vibrations during use to prevent cracking or damage.

    Control Temperature Appropriately

    When using bent quartz glass tubing in high-temperature environments, carefully control the temperature to avoid exceeding the maximum operating temperature, which could cause deformation or damage.

    Avoid Contact with Chemicals

    Minimize direct contact between bent quartz glass tubing and corrosive chemicals such as strong acids and alkalis to prevent corrosion and damage.

    Regular Maintenance and Care

    Regularly inspect and maintain the bent quartz glass tubing to identify and address any potential issues promptly. This ensures proper function and extends the lifespan of the tubing.

    Quartz bending tubes possess high thermal stability, optical clarity, chemical resistance, and electrical insulation. They can withstand very high temperatures, have low thermal expansion, and are highly transparent to a broad spectrum of light, including UV and visible light. They are also chemically inert, highly pure, and offer excellent electrical insulation even at high temperatures.

    Quartz bending tubes are used in high-temperature furnaces, chemical reactions, spectroscopy, semiconductor manufacturing, UV sterilization, industrial heating, and optical devices. Their versatility makes them essential in industries such as semiconductor manufacturing, laboratory research, UV sterilization, and optical photonics.

    Quartz bending tubes are manufactured through a special process that involves melting high-purity quartz sand at high temperatures. This process ensures that the tubes maintain their high purity (99.99% SiO2), high transparency, and other critical properties.

    1.石英激光打孔

    Laser Drilling of Quartz

    Quartz Tube with External Threads

    Threaded Quartz Tube

    3.管面螺纹

    External Thread on Quartz Tube

    Quartz Tube with Internal Threads

    Internal Threaded Quartz Tube

    Slotting of Quartz Tube Walls

    Quartz Tube Slotted

    Creating Windows on Quartz Tube Surface

    Window on Quartz Tube

    Angled Cutting of Quartz Tube

    Angled Cut Quartz Tube

    Quartz Tiles/Quartz Plates

    Quartz Tile

    Cutting Windows in Quartz Tube

    Quartz Tube with Window
