Milky quartz tubing, formed by incorporating specific dyes or oxides during the manufacturing process, results in an opaque white quartz material. Primarily composed of high-purity quartz glass, it exhibits exceptional resistance to high temperatures, corrosion, and aging.
OD | ID | WT | L(mm) |
---|---|---|---|
1mm | 0.5mm | 0.25mm | 1~6000mm(custom) |
1.5mm | 0.8mm | 0.35mm | 1~6000mm(custom) |
2mm | 1mm | 0.5mm | 1~6000mm(custom) |
2.5mm | 1.5mm | 0.5mm | 1~6000mm(custom) |
3mm | 2mm | 0.5mm | 1~6000mm(custom) |
3mm | 1mm | 1mm | 1~6000mm(custom) |
4mm | 3mm | 0.5mm | 1~6000mm(custom) |
4mm | 2mm | 1mm | 1~6000mm(custom) |
4mm | 1mm | 1.5mm | 1~6000mm(custom) |
5mm | 4mm | 0.5mm | 1~6000mm(custom) |
5mm | 3mm | 1mm | 1~6000mm(custom) |
5mm | 2mm | 1.5mm | 1~6000mm(custom) |
5.5mm | 3.5mm | 1mm | 1~6000mm(custom) |
6mm | 5mm | 0.5mm | 1~6000mm(custom) |
6mm | 4mm | 1mm | 1~6000mm(custom) |
6mm | 3mm | 1.5mm | 1~6000mm(custom) |
6mm | 2mm | 2mm | 1~6000mm(custom) |
6.5mm | 4.5mm | 1mm | 1~6000mm(custom) |
7mm | 5mm | 1mm | 1~6000mm(custom) |
7mm | 4mm | 1.5mm | 1~6000mm(custom) |
7.5mm | 5.5mm | 1mm | 1~6000mm(custom) |
8mm | 6mm | 1mm | 1~6000mm(custom) |
8mm | 5mm | 1.5mm | 1~6000mm(custom) |
8.5mm | 6.5mm | 1mm | 1~6000mm(custom) |
9mm | 7mm | 1mm | 1~6000mm(custom) |
9mm | 6mm | 1.5mm | 1~6000mm(custom) |
9mm | 5mm | 2mm | 1~6000mm(custom) |
10mm | 8mm | 1mm | 1~6000mm(custom) |
10mm | 7mm | 1.5mm | 1~6000mm(custom) |
10mm | 6mm | 2mm | 1~6000mm(custom) |
10mm | 4mm | 3mm | 1~6000mm(custom) |
10mm | 2mm | 4mm | 1~6000mm(custom) |
11mm | 9mm | 1mm | 1~6000mm(custom) |
11mm | 8mm | 1.5mm | 1~6000mm(custom) |
11mm | 7mm | 2mm | 1~6000mm(custom) |
11mm | 5mm | 3mm | 1~6000mm(custom) |
12mm | 10mm | 1mm | 1~6000mm(custom) |
12mm | 8mm | 2mm | 1~6000mm(custom) |
12mm | 4mm | 4mm | 1~6000mm(custom) |
13mm | 11mm | 1mm | 1~6000mm(custom) |
13mm | 10mm | 1.5mm | 1~6000mm(custom) |
13mm | 9mm | 2mm | 1~6000mm(custom) |
14mm | 12mm | 1mm | 1~6000mm(custom) |
14mm | 10mm | 2mm | 1~6000mm(custom) |
15mm | 13mm | 1mm | 1~6000mm(custom) |
15mm | 11mm | 2mm | 1~6000mm(custom) |
15mm | 9mm | 3mm | 1~6000mm(custom) |
16mm | 14mm | 1mm | 1~6000mm(custom) |
16mm | 13mm | 1.5mm | 1~6000mm(custom) |
16mm | 12mm | 2mm | 1~6000mm(custom) |
16mm | 10mm | 3mm | 1~6000mm(custom) |
17mm | 15mm | 1mm | 1~6000mm(custom) |
17mm | 14mm | 1.5mm | 1~6000mm(custom) |
18mm | 16mm | 1mm | 1~6000mm(custom) |
18mm | 15mm | 1.5mm | 1~6000mm(custom) |
18mm | 14mm | 2mm | 1~6000mm(custom) |
18mm | 12mm | 3mm | 1~6000mm(custom) |
18mm | 11mm | 3.5mm | 1~6000mm(custom) |
19mm | 17mm | 1mm | 1~6000mm(custom) |
19mm | 16mm | 1.5mm | 1~6000mm(custom) |
19mm | 13mm | 3mm | 1~6000mm(custom) |
20mm | 18mm | 1mm | 1~6000mm(custom) |
20mm | 17mm | 1.5mm | 1~6000mm(custom) |
20mm | 16mm | 2mm | 1~6000mm(custom) |
20mm | 14mm | 3mm | 1~6000mm(custom) |
25mm | 19mm | 3mm | 1~6000mm(custom) |
25mm | 21mm | 2mm | 1~6000mm(custom) |
25mm | 21mm | 2mm | 1~6000mm(custom) |
25mm | 21mm | 2mm | 1~6000mm(custom) |
25mm | 21mm | 2mm | 1~6000mm(custom) |
25mm | 20mm | 2.5mm | 1~6000mm(custom) |
25mm | 20mm | 2.5mm | 1~6000mm(custom) |
25mm | 20mm | 2.5mm | 1~6000mm(custom) |
26mm | 21mm | 2.5mm | 1~6000mm(custom) |
28mm | 24mm | 2mm | 1~6000mm(custom) |
30mm | 26mm | 2mm | 1~6000mm(custom) |
30mm | 24mm | 3mm | 1~6000mm(custom) |
35mm | 30mm | 2.5mm | 1~6000mm(custom) |
40mm | 34mm | 3mm | 1~6000mm(custom) |
40mm | 34mm | 3mm | 1~6000mm(custom) |
40mm | 34mm | 3mm | 1~6000mm(custom) |
40mm | 34mm | 3mm | 1~6000mm(custom) |
40mm | 32mm | 4mm | 1~6000mm(custom) |
40mm | 32mm | 4mm | 1~6000mm(custom) |
40mm | 32mm | 4mm | 1~6000mm(custom) |
40mm | 32mm | 4mm | 1~6000mm(custom) |
40mm | 32mm | 4mm | 1~6000mm(custom) |
45mm | 39mm | 3mm | 1~6000mm(custom) |
50mm | 44mm | 3mm | 1~6000mm(custom) |
50mm | 44mm | 3mm | 1~6000mm(custom) |
50mm | 44mm | 3mm | 1~6000mm(custom) |
50mm | 44mm | 3mm | 1~6000mm(custom) |
50mm | 44mm | 3mm | 1~6000mm(custom) |
50mm | 44mm | 3mm | 1~6000mm(custom) |
50mm | 44mm | 3mm | 1~6000mm(custom) |
50mm | 44mm | 3mm | 1~6000mm(custom) |
50mm | 44mm | 3mm | 1~6000mm(custom) |
50mm | 44mm | 3mm | 1~6000mm(custom) |
50mm | 42mm | 4mm | 1~6000mm(custom) |
50mm | 42mm | 4mm | 1~6000mm(custom) |
50mm | 42mm | 4mm | 1~6000mm(custom) |
50mm | 42mm | 4mm | 1~6000mm(custom) |
50mm | 42mm | 4mm | 1~6000mm(custom) |
50mm | 42mm | 4mm | 1~6000mm(custom) |
50mm | 40mm | 5mm | 1~6000mm(custom) |
50mm | 40mm | 5mm | 1~6000mm(custom) |
60mm | 54mm | 3mm | 1~6000mm(custom) |
60mm | 54mm | 3mm | 1~6000mm(custom) |
60mm | 54mm | 3mm | 1~6000mm(custom) |
60mm | 54mm | 3mm | 1~6000mm(custom) |
60mm | 52mm | 4mm | 1~6000mm(custom) |
60mm | 52mm | 4mm | 1~6000mm(custom) |
60mm | 50mm | 5mm | 1~6000mm(custom) |
60mm | 50mm | 5mm | 1~6000mm(custom) |
80mm | 74mm | 3mm | 1~6000mm(custom) |
80mm | 74mm | 3mm | 1~6000mm(custom) |
80mm | 74mm | 3mm | 1~6000mm(custom) |
80mm | 72mm | 4mm | 1~6000mm(custom) |
80mm | 72mm | 4mm | 1~6000mm(custom) |
80mm | 70mm | 5mm | 1~6000mm(custom) |
80mm | 70mm | 5mm | 1~6000mm(custom) |
85mm | 79mm | 3mm | 1~6000mm(custom) |
90mm | 80mm | 5mm | 1~6000mm(custom) |
100mm | 94mm | 3mm | 1~6000mm(custom) |
100mm | 94mm | 3mm | 1~6000mm(custom) |
100mm | 94mm | 3mm | 1~6000mm(custom) |
100mm | 92mm | 4mm | 1~6000mm(custom) |
100mm | 92mm | 4mm | 1~6000mm(custom) |
100mm | 90mm | 5mm | 1~6000mm(custom) |
100mm | 90mm | 5mm | 1~6000mm(custom) |
120mm | 112mm | 4mm | 1~6000mm(custom) |
120mm | 110mm | 5mm | 1~6000mm(custom) |
120mm | 112mm | 4mm | 1~6000mm(custom) |
120mm | 110mm | 5mm | 1~6000mm(custom) |
130mm | 120mm | 5mm | 1~6000mm(custom) |
130mm | 124mm | 3mm | 1~6000mm(custom) |
130mm | 124mm | 3mm | 1~6000mm(custom) |
130mm | 120mm | 5mm | 1~6000mm(custom) |
130mm | 120mm | 5mm | 1~6000mm(custom) |
140mm | 130mm | 5mm | 1~6000mm(custom) |
140mm | 130mm | 5mm | 1~6000mm(custom) |
150mm | 140mm | 5mm | 1~6000mm(custom) |
150mm | 140mm | 5mm | 1~6000mm(custom) |
150mm | 140mm | 5mm | 1~6000mm(custom) |
180mm | 170mm | 5mm | 1~6000mm(custom) |
180mm | 170mm | 5mm | 1~6000mm(custom) |
180mm | 170mm | 5mm | 1~6000mm(custom) |
200mm | 190mm | 5mm | 1~6000mm(custom) |
200mm | 190mm | 5mm | 1~6000mm(custom) |
200mm | 190mm | 5mm | 1~6000mm(custom) |

- ayment method: By wire transfer or advance payment, depending on the quantity of the order.
- Delivery time: According to the order quantity.
- Transportation method: Sea freight or air freight, depending on the customer.
Remarks:
To confirm the order, the following parameters need to be provided: ① OD ② ID ③ Thickness ④ Lengt ⑤ Quantity
Property Content | Property Values |
---|---|
SiO2 | 99.99% |
Density | 2.2×10³ kg/cm³ |
Hardness | 5.5 - 6.5 Mohs' Scale 570 KHN 100 |
Tensile Strength | 4.8×10⁷ Pa (N/mm2) (7000 psi) |
Compression Strength | >1.1×10⁹ Pa (160,000 psi) |
Coefficient of Thermal Expansion | 5.5×10⁻⁷ cm/cm·°C (20°C-320°C) |
Thermal Conductivity | 1.4 W/m·°C |
Specific Heat | 670 J/kg·°C |
Softening Point | 1730°C (3146°F) |
Annealing Point | 1210°C (2210°F) |
Strain Point | 1120°C (2048°F) |
Work Temperature | 1200°C (2192°F) |
Electrical Resistivity | 7×10⁷ ohm cm (350°C) |
Size | Customized |
Logo | Customized Logo Accept |
High Thermal Resistance
Can be used in high-temperature environments for extended periods without deformation or damage.
Strong Corrosion Resistance
Impervious to corrosion from common chemicals.
High Translucency
Despite its milky white appearance, it retains good light transmission, resists staining, and is easy to clean.
High Hardness
Possesses high hardness, enabling it to withstand a degree of physical impact.
Application Scenario
Prevent Impacts and Vibrations
Safeguard the tubing from impacts and vibrations to prevent breakage and deformation.
Controlled Heating
When using milky quartz tubing for high-temperature applications, carefully select appropriate heating methods and temperatures based on its thermal resistance and the operating environment. Avoid excessive temperatures that could lead to deformation or damage.
Avoid Chemical Contact
Prevent contact with chemicals, especially acids and alkalis, to protect the tubing from corrosion or discoloration.
Regular Maintenance
Clean the tubing with a soft cloth and warm water. Avoid abrasive materials or strong acidic/alkaline solutions. Protect the tubing from direct sunlight and high-temperature environments to prevent aging and deformation.
Milky quartz tubes are primarily used in applications requiring far-infrared heating, such as heaters, disinfection cabinets, microwave ovens, and other electric heating devices.
Milky quartz tubes are opaque and milky white in appearance due to a special manufacturing process. They have excellent thermal stability and can absorb and convert visible light and near-infrared radiation into far-infrared radiation.
Milky quartz tubes have less than 10% light transmittance at 500nm, which is significantly lower than that of clear quartz tubes, providing better opacity.
