Laboratory and Chemical ApplicationsOur custom quartz flow cells and fused silica optical cuvettes are precisely designed for continuous fluid analysis and reaction monitoring. Featuring integrated ports for seamless liquid handling, these high-purity components offer exceptional UV-Vis transmission, superior chemical resistance, and high thermal stability. Ideal for spectroscopy, chromatography, and custom microfluidic applications, we engineer bespoke solutions to meet your specific optical and fluidic requirements.
| Property Content | Property Values |
|---|---|
| SiO2 | 99.99% |
| Density | 2.2×10³ kg/cm³ |
| Hardness | 5.5 - 6.5 Mohs' Scale 570 KHN 100 |
| Tensile Strength | 4.8×10⁷ Pa (N/mm2) (7000 psi) |
| Compression Strength | >1.1×10⁹ Pa (160,000 psi) |
| Coefficient of Thermal Expansion | 5.5×10⁻⁷ cm/cm·°C (20°C-320°C) |
| Thermal Conductivity | 1.4 W/m·°C |
| Specific Heat | 670 J/kg·°C |
| Softening Point | 1730°C (3146°F) |
| Annealing Point | 1210°C (2210°F) |
| Strain Point | 1120°C (2048°F) |
| Work Temperature | 1200°C (2192°F) |
| Electrical Resistivity | 7×10⁷ ohm cm (350°C) |
| Size | Customized |
| Logo | Customized Logo Accept |
High Light Transmittance
Quartz cuvettes have extremely high light transmittance in the ultraviolet to visible light regions, particularly in the ultraviolet region. This is essential for experiments that require precise measurements within this wavelength range.
Excellent Chemical Resistance
The quartz material is resistant to strong acids, bases, and organic solvents, ensuring the stability and durability of the cuvettes in a variety of chemical environments.
Precise Optical Properties
The optical surfaces of quartz cuvettes are precision-machined to ensure accuracy and repeatability in spectroscopic analysis.
Wide Applicability
These cuvettes are compatible with various spectroscopic instruments, such as spectrophotometers, and can be used for quantitative and qualitative analysis of substances in both the 200-400nm ultraviolet range and the visible light region.
Application Scenario
Chemical Analysis
In chemical laboratories, quartz cuvettes are used to measure the absorbance of solutions and perform quantitative analysis of chemical reactions, particularly in experiments that require measurements in the ultraviolet region.
Biomedical Research
In biochemistry and molecular biology, quartz cuvettes are used to measure the concentration and purity of biomolecules such as DNA, RNA, and proteins.
Environmental Monitoring
Quartz cuvettes are used for water quality analysis and the detection of environmental pollutants, such as measuring heavy metal ions and organic pollutants in water samples.
Pharmaceutical Analysis
In the pharmaceutical industry, quartz cuvettes are used for the quantitative analysis of drug components to ensure that drug concentrations and purity meet established standards, as well as for conducting drug stability tests.
The high light transmittance of quartz cylindrical cuvettes in the ultraviolet region is essential for experiments requiring precise measurements in this wavelength range. Many biomolecules and chemical substances have characteristic absorptions in the ultraviolet region, which are crucial for their quantitative analysis and identification.
When using quartz cuvettes, avoid touching the optical surfaces to prevent contamination. Thoroughly clean and properly store them before and after use to maintain their performance. Also, because quartz material is fragile, handle with care to prevent damage.
When cleaning quartz cuvettes, gently wipe with a mild detergent and a soft cloth, avoiding hard brushes or abrasives that could scratch the surface. After cleaning, thoroughly rinse and air-dry or wipe with a lint-free cloth. For long-term storage, store them in a suitable cuvette box, avoiding direct sunlight and high-temperature environments to extend their lifespan.
Quartz XRD Sample Holder
Quartz flow cells
Quartz Petri Dish
Custom Quartz Petri Dish
Quartz Cylindrical Cuvette
Quartz Round Screw-Top Cuvette
Frequently asked questions
We specialize in the end-to-end manufacturing of high-purity quartz glass components. Our core product lines include:
Quartz Tubing & Rods: A wide range of diameters and specifications.
Quartz Plates & Discs: Precision-cut and polished for optical and industrial use.
Quartz Labware: A full suite of standard and custom glassware, including beakers, flasks, and boats.
Semiconductor-Grade Quartz: High-purity components like process tubes and carriers for semiconductor fabrication.
Custom Fabricated Components: We can produce complex parts tailored to your unique designs and specifications.
Yes. Custom fabrication is at the core of our business. With over a decade of specialized experience, we partner with companies to provide expert OEM/ODM services. Our capabilities include welding, grinding, drilling, polishing, bending, and other precision processing techniques to create components that meet your exact requirements.
Quality is paramount in our manufacturing process. We are an ISO 9001:2015 certified manufacturer, ensuring that our processes meet international quality management standards.Our products also undergo rigorous SGS testing for purity and performance. We use high-purity raw materials (up to 99.998% SiO2) to produce fused quartz and fused silica products with exceptional thermal stability, high-temperature resistance, and chemical inertness.
We've streamlined our process to be as efficient as possible:
Submit Your RFQ: Send us your technical drawings, specifications, and requirements via our website contact form or email.
Rapid Response: You can expect an initial response within minutes and detailed communication within half an hour.
Design & Proposal: We will deliver a detailed design proposal and a competitive quote within 24 hours.
Prototyping & Production: Upon approval, we move swiftly from prototyping to full-scale production to meet your deadlines.
Partnering with Aoxin Quartz offers several key advantages:
Proven Expertise: With 10+ years in the industry, we have the technical knowledge to tackle complex challenges.
One-Stop Solution: We manage the entire production process, from sourcing high-purity raw materials to fabricating and finishing complex components.
Competitive Value: Located in a major quartz production hub, we leverage an efficient supply chain and advanced manufacturing to offer exceptional quality at a competitive price point.
Dedicated Partnership: Over 90% of our clients become long-term partners. We are committed to your success through responsive service, reliable quality, and innovative solutions.
